Generally the base which is bolted into a huge concrete pad provides the essential support for a tower crane. The base is connected to a tower or a mast and stabilizes the crane which is attached to the inside of the building's structure. Usually, this attachment point is to an elevator shaft or to a concrete lift.
The crane's mast is often a triangulated lattice structure which measures 10 feet square or 0.9m2. Connected to the very top of the mast is the slewing unit. The slewing unit consists of a gear and a motor that allows the crane to rotate.
Tower cranes may have a max unsupported height of 80m or 265 feet, while the tower crane's maximum lifting capacity is 16,642 kg or 39,690 pounds with counter weights of 20 tons. In addition, two limit switches are utilized to be able to ensure the driver does not overload the crane. There is also one more safety feature called a load moment switch to ensure that the operator does not surpass the ton meter load rating. Finally, the tower crane has a maximum reach of 70 meters or 230 feet.
Due to their extreme heights, there is a science involved to erecting a crane. The stationary structure would first have to be transported to the construction location by utilizing a big tractor-trailer rig setup. Then, a mobile crane is used so as to assemble the machine part of the crane and the jib. These parts are then connected to the mast. Afterward, the mobile crane adds counterweights. Crawler cranes and forklifts may be a few of the other industrial machines that is commonly used to erect a crane.
When the building is erected, mast extensions are added to the crane. This is how the crane's height could match the building's height. The crane crew uses what is referred to as a climbing frame or a top climber which fits between the slewing unit and the top of the mast. A weight is hung on the jib by the work crew so as to balance the counterweight. When complete, the slewing unit can detach from the top of the mast. In the top climber, hydraulic rams are utilized to adjust the slewing unit up an extra 6.1m or 20 feet. Next, the crane driver utilizes the crane to insert and bolt into position another mast part piece.
